特性及功能

• L-CD材質為100%經特殊耐摺曲處理之鐵氟龍CBF, (耐摺性能為同厚度一般PTFE之7.8倍, FEP之1276倍, PFA之1510倍)
• 撕裂強度遠大於其它氟化塑膠材料(達6倍左右)
• 抗酸鹼腐蝕性能與PTFE相同, PH 0-14
• 不可燃, 符合FM Class 4910, UL 94V-0,
• 使用壽命遠超過其它任何PTFE, FEP, PFA等材質
• 適用於正壓及負壓管線
• 補強環材質為不銹鋼或PTFE材質
• 使用溫度-73°C至260°C
• 化工廠, 半導體廠, 腐蝕性氣體或低壓流體輸送管線及食品, 製藥, 生化廠無污染輸送管線

• L-CD Flexible Hose are made of CBF which is 100% specially formulated PTFE material with superior cracking resistance (7.8 times of standard PTFE, 1276 times of FEP and 1510 times of PFA)
• 6 times stronger tear strength than other perfluoroplastic materials
• Excellent chemical resistance PH 0-14
• Flame resistance to FM4910 and UL94V-O
• Application temperature range from -73°C to 260°C
• Suitable for pipeline with corrosive flow medium and non-contaminated pipeline for food, medicine, bio-chemical plants.

PTFE Ring CBF補強環

Stainless Steel Ring 不銹鋼補強環
